Description
E50SF102 Sprocket is a triple 102-tooth quick detachable (QD) style sprocket that utilizes an SF QD Bushing. Our triple E50SF102 sprocket is dimensionally manufactured following ANSI Standards, which essentially means that it directly interchanges with other brands. More specifically to our sprocket, it is made utilizing high-quality mild steel and is made with high precision tolerances for optimal long-term performance. Besides the sprocket, we also stock SF bushings, 50-3 Roller Chain, v-belts, v-belt pulleys, electric motors, gear reducers, bearings, and much more! For more information or to get a quote please contact our customer service team and we will be happy to assist you.
E50SF102 Sprocket Dimensions
- Sprocket Size: E50SF102
- Tooth Count: 102
- Bushing Used: SF
- Outside Diameter: 20.660″
- Pitch Diameter: 20.295″
- Sprocket Type: B
- Maximum Bushing Bore: 2-15/16″
- Dimension (L1): 2-1/4″
- Dimension (L2): 2-1/4″
- Dimension (C): 4-5/8″
- Dimension (Y): 1/4″
- Dimension (V): 1/2″
- Dimension (X): 1/4″
- Dimension (T): 0.332″
- Dimension (W): 1.758″
- Sprocket Weight: 103.2 LBS
