Description
This D16BTB19 sprocket is a metric taper bushed style roller chain sprocket manufactured under ISO and British Standard 228. and is made to accept a 3020 taper bushing. Our D16BTB19 sprockets are made with reliability and performance in mind, so we use high-quality carbon steel (CS) and have the sprocket precision cut to ensure maximum performance and wear life. We also offer upgrades on our D16BTB19 sprockets such as black-oxide coatings and heat-treated hardened teeth, though we often have these specific sprockets with those features already added right off the shelf. Besides the 19 tooth sprocket, we also stock a high-quality 16B roller chain, 3020 bushings, and a wide array of roller chain accessories. For more information or to get a quote on taper bushed D16BTB19 sprockets, please contact us and one of our sales team members will be happy to assist you.
D16BTB19 Sprocket Dimensions
- Sprocket Size: D16BTB19
- Tooth Count: 19
- Pitch Diameter: 154.32mm
- Bushing Size: 3020
- Maximum Bushing Bore Size: 76.20mm
- Length Thru Bore (L): 50.80mm
- Hub Diameter (C): 127.00mm
- Sprocket Weight: 3.18 kG
- Bushing Weight: 2.95 kG
