Description
SB209-27 bearing is a light-duty ball bearing insert made to C3 precision standards and utilizes set-screws to secure to a 1-11/16″ shaft. Our SB209-27 insert bearing has several features: a wide inner-ring, steel retainer, anti-rotation device, and an inner ring and outer ring made from bearing grade steel to produce a high-quality and long-lasting bearing. Our SB209-27 bearing is made to industry standards dimensionally for direct interchangeability with just about any brand. For additional information or to receive a quote on our SB209-27 bearings, contact our customer service and, we will be happy to assist you!
SB209-27 Bearing Dimensions
- Part #: SB209-27
- Shaft Diameter (d): 1-11/16″
- Setscrew Used: 5/16-24
- Dimension (D): 3.3465″
- Dimension (Bi): 1.4173″
- Dimension (Be): 0.7480″
- Dimension (N): 0.3740″
- Dimension (M): 1.2205″
- Dimension (G): 0.3150″
- Dimension (T): 0.2402″
- Dynamic Load Rating (LBS): 7,160
- Static Load Rating (LBS): 4,676
- Weight (LBS): 1.8
