Description
UEST206-20 bearing is a 1-1/4″ bore normal-duty take-up bearing that utilizes a Tru-Loc device to secure to a 1-1/4″ shaft. UEST206-20 take-up bearings are designed for take-up frames, which creates an assembly that maintains and adjusts tension for conveyor and drive systems. Our superior UEST206-20 bearing with a 1-1/4″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid cast-iron housing. Additionally, our UEST206-20 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. Our UEST206-20 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UEST206-20 bearings, and we will be happy to assist you!
UEST206-20 Take-Up Bearing Dimensions
- Part #: UEST 206-20
- Shaft Diameter (d): 1-1/4″
- Dimension (O): 0.63″
- Dimension (G): 0.39″
- Dimension (P): 2.19″
- Dimension (Q): 1.47″
- Dimension (S): 0.88″
- Dimension (B): 2.25″
- Dimension (K): 0.53″
- Dimension (E): 3.50″
- Dimension (A): 4.00″
- Dimension (W): 4.44″
- Dimension (J): 1.47″
- Dimension (L): 1.13″
- Dimension (H): 2.75″
- Dimension (Bi): 1.5669″
- Dimension (N): 0.6260″
- Dimension (M): 0.8740″
- Dynamic Load Rating (LBS): 4,377
- Static Load Rating (LBS): 2,569
- Bearing Insert: UE 206-20
- Housing Number: ST 206
- Weight (LBS): 2.9
