Uc211-34 2-1/8″ Insert Bearing Unit

Description

UC211-34 bearing is a normal-duty ball bearing insert made to C3 precision standards and utilizes set screws for securing a 2-1/8″ shaft. Our UC211-34 insert bearing has several features: a wide inner-ring, steel retainer, anti-rotation device, and an inner ring and outer ring made from bearing grade steel to produce a high-quality and long-lasting bearing. Our UC211-34 bearing is made to industry standards dimensionally for direct interchangeability with just about any brand. For additional information or to receive a quote on our UC211-34 bearings, contact our customer service and, we will be happy to assist you!

UC211-34 Bearing Dimensions

• Part #: UC 211-34
• Shaft Diameter (d): 2-1/8″
• Setscrew Used: 3/8-24
• Dimension (D): 3.9370″
• Dimension (Bi): 2.1890″
• Dimension (Be): 0.9843″
• Dimension (N): 0.8740″
• Dimension (M): 1.3150″
• Dimension (G): 0.3937″
• Dimension (T): 0.2913″
• Dynamic Load Rating (LBS): 9,743
• Static Load Rating (LBS): 6,608
• Weight (LBS): 2.4
