Description
This D140J45 sprocket is a high-quality, precision, and durable QD type sprocket that has 45 teeth. D140J45 sprockets use an J-Type QD Bushing and are a solid construction sprocket. Something that is notable about this sprocket is that it fully meets all ANSI Standards, which insures proper contact between the #140-2 double roller chain and sprocket thus preventing premature wear or breakage and this means that it will directly interchange with most other manufactures sprockets. This sprocket is also black oxide coated which increases resistance to the environment, preventing early rust build up. Along with the D140J45 sprocket, we offer a full line of premium J-Type QD bushings right off the shelf and at great pricing. We also offer sprockets with finished bore configurations, and if you are needing a custom bore sprocket we the capabilities on providing those to within a fast lead time and at really great prices. For more information please contact us and we will be happy to assist you.
Dimensions:
- Sprocket Size: D140J45
- Tooth Count: 45
- Bushing Type: J
- Outside Diameter: 26.080″
- Pitch Diameter: 25.087″
- Sprocket Type: C5
- Maximum Bore: 4-7/16″
- Dimension (L1): 4-1/2″
- Dimension (L2): 5″
- Dimension (C): 7-1/4″
- Dimension (Y): 31/32″
- Dimension (P): 23/32″
- Dimension (G): 19/32″
- Dimension (V): 7/32″
- Dimension (X): 3-3/16″
- Dimension (T): 0.894″
- Dimension (W): 2.818″
- Bushing Weight: 18.0 LBS
- Sprocket Weight: 176.0 LBS
