Description
This D100R22 sprocket is a durable, high quality, and precision double sprocket with 22 hardened teeth that is manufactured to accept a R1 bushing. Sprockets that have hardened teeth last longer and are much more durable than those that don’t. Something else that is notable about this sprocket is that it fully meets all ANSI Standards, which insures proper contact between the #100-2 double roller chain and sprocket thus preventing premature wear or breakage. This sprocket is also black oxide coated which increases resistance to the environment and will prevent early rust build up. Besides the D100R22 sprocket we offer a full line of premium R1 bushings right off the shelf. We also offer sprockets with finished bore configurations, and if you are needing a custom bore sprocket we the capabilities of providing those as well. For more information please contact us and we will be happy to assist you.
Dimensions:
- Sprocket Size: D100R22
- Tooth Count: 22
- Bushing Type: R1
- Outside Diameter: 9.440″
- Pitch Diameter: 8.783″
- Sprocket Type: 14
- Maximum Bore: 3-3/4″
- Dimension (OL): 3-7/32″
- Dimension (L): 2-7/8″
- Dimension (C): 1/16″
- Dimension (H): 5-3/8″
- Dimension (P): 7/8″
- Dimension (T): 0.669″
- Bushing Weight: 7.5 LBS
- Sprocket Weight: 22.8 LBS
